EnvelopExpress
The EnvelopExpress is an optional envelope feeder designed for the MGI digital presses. It is available for both the Meteor DP40 & DP60 Pro models.
An ideal solution for short and medium run jobs, the EnvelopExpress allows customers to easily integrate four-color process and fully personalized envelope (with variable data) printing capability into their digital portfolio. This feeder allows for continuous delivery, maximizing output volume without interruption of the production cycle.
It accommodates a wide range of envelope formats - with or without window - including C6, C5, C6/C5, DL & C4. For non standard envelope sizes, the supported lengths are ranging from 200 mm (7.8") up to 300 mm (11.8").
In addition, the EnvelopExpress® is designed to ensure a fast transition between paper and plastic substrates, allowing the user to remove the feeder and returning to cut sheet mode within minutes. The feeder is designed to complement the high volume capacity of the Meteor DP40/DP60 Pro, which can handle several thousands A4/Letter sheets per hour.
The EnvelopExpress® has a capacity of approximately 1,000* envelopes at once; however, "on-the-fly" reloading is possible without interrupting the printing production.
An ideal solution for short and medium run jobs, the EnvelopExpress allows customers to easily integrate four-color process and fully personalized envelope (with variable data) printing capability into their digital portfolio. This feeder allows for continuous delivery, maximizing output volume without interruption of the production cycle.
It accommodates a wide range of envelope formats - with or without window - including C6, C5, C6/C5, DL & C4. For non standard envelope sizes, the supported lengths are ranging from 200 mm (7.8") up to 300 mm (11.8").
In addition, the EnvelopExpress® is designed to ensure a fast transition between paper and plastic substrates, allowing the user to remove the feeder and returning to cut sheet mode within minutes. The feeder is designed to complement the high volume capacity of the Meteor DP40/DP60 Pro, which can handle several thousands A4/Letter sheets per hour.
The EnvelopExpress® has a capacity of approximately 1,000* envelopes at once; however, "on-the-fly" reloading is possible without interrupting the printing production.
Envelope Production System | |
| Format | Minimum: 100 X 140 mm 4 x 5.5 Inches Maximum: 315 X 360 mm 2.4 x 14.2 Inches C6, C5, C6/C5, DL & C4 standard envelope sizes |
| Speed | 1,200 Envelopes Per Hour |
| Capacity | Load up to 1000 Envelopes at a time Re-load on the Fly without having to stop production |
| Feed | Air feeding Offset registration |
| Compatible With | Meteor DP8700 XL Meteor DP60 Pro Meteor DP40 Pro |
| Option | High Capacity Delivery Stream Output Table Dimensions: 140 x 42 x 130 cm 55.1" x 16.5" x 51.1" Inches Weight: 15 kg 33 lbs |
| Electrical Requirements | Electrical power supply: 230 V / 50 Hz Electrical protection: 16 Amps |
| Dimensions | L x w x H: 120 cm x 60 cm x 100 cm 47.2" x 23.6" x 39,3" Inches |
| Weight | 88 kg 194 lbs |
Product Advantages
High Margin Market |
Added Value |
Easy of Use |
Reload On the Fly |
Variable Data |
